Membrane switches are a critical component of many electronic devices that most of us use everyday. The better a membrane switch is designed, the better it works and the longer it lasts. Here are six useful tips to help ensure your membrane switch design is a success.

Basic membrane switch design is key to good design. Membrane switches are sheets of materials that communicate with one another when you press them down. The layers include a graphic overlay layer, a top circuit layer, a spacer layer, and a bottom circuit layer. Every layer contributes to getting the membrane switch to work properly.

​

“Having that the emembrane button switch be durable and reliable is so important. If you use good materials, and be sure your layers stick well, this switch will work properly, and won’t wear out quickly in shafts. This is significant since a switch may be activated many times during its service life.

Picking out the correct materials for the membrane switch is crucial to the success of it functioning. Alternative materials have specific properties that can effect the way the switch operates. For instance, the switch can bend without breaking if the spacer is made with a flexible material. A more durable material for the graphic overlay can protect the design from wear and fading.

The switch should also be easy to use. This requires thinking about how the switch might be used, its location on the device and what it will switch. Items like the size, location, and labeling of buttons are key to make the switch simple to understand and tactility easy to use.

It is crucial that you test your membrane keypad switch design. This can help to identify problems that should be fixed before the switch is made. Solving any problem during the test can ensure the switch works properly and reliably. If followed, these six tips will lead to the creation of a quality membrane switch design that is rugged, dependable, and user-friendly for nearly any electronic application.
